Rivian R1T / R1S RMaxx Aluminum Running Boards — Installed
Fits Rivian R1T and R1S, Gen 1 and Gen 2. Installed price includes parts, labor, and sales tax.
These are running boards, not rock sliders.
The RMaxx aluminum running boards are designed to add easier cabin access to the Rivian R1T and R1S while maintaining an OEM-style appearance and minimizing added weight. The aluminum construction helps keep the system significantly lighter than comparable steel running boards and also eliminates rust concerns if the powder coating is scratched.
Why Choose the Aluminum RMaxx Running Boards?
- Lightweight aluminum running-board frames and tread plates
- Stainless-steel mounting brackets
- Welded tread plates for a cleaner appearance and easier installation
- Low-profile mounting system designed to preserve ground clearance
- Designed to stay within the vehicle's aerodynamic profile to minimize range impact
- Compatible with Rivian Reinforced Underbody Shield / RUS configurations
Vehicle Fitment
- Rivian R1T: 2021–present
- Rivian R1S: 2022–present
R1T and R1S use different-length running boards and are not interchangeable. Select the correct vehicle from the product options.
Installation Options
The running boards bolt directly to the Rivian frame. Access to the mounting points requires removing or modifying the factory lower plastic trim.
Available installation choices may include trim removal, 4-inch access holes, taped access holes, or optional aero cover plates. If the taped-hole option is selected, the jack-point opening will remain accessible for tire rotations and service.
Specifications
- Aluminum-alloy running-board frames and tread plates
- 300-series stainless-steel brackets
- Textured black electrostatic powder-coated finish
- Approximate weight: R1T 22 lbs per side; R1S 18 lbs per side
- Designed for minimal wind-noise and aerodynamic impact
- Jack-point access retained for service and lifting
Optional aero cover plates are available for owners who want a more finished lower-body appearance after installation.
